Name: LB-602VK2, LB-602VK2 2 Digit 7-Segment LED Display, CC Red 16 mcd RH DP 14.2mm
Brand: Rohm
SKU: LB-602VK2

Оптоэлектроника Индикаторы и дисплеи ЖК дисплеи Rohm LB-602VK2, LB-602VK2 2 Digit 7-Segment LED ...

Подробное описание

1 490 ₽

– +

Бонус: 29.8 !

Бонусная программа

Итого: 1 490 ₽

Купить

Displays & Optoelectronics\Display Modules\LED Displays2 digit LED numeric displays with a black background for high contrast.

Основные
Производитель	Rohm
Бренд	Rohm
Информация о производителе
base product number	LB-602 ->
character width	8mm
color	Red
colour of face	Black
common connection	Cathode
common pin	Common Cathode
current - test	10mA
Дата загрузки	12.05.2024
decimal orientation	Right Side
digit/alpha size	0.56"" (14.30mm)
display type	7-Segment
dominant wavelength	650 nm
eccn	EAR99
external dimensions	25x8x19mm
external width	25mm
forward current	20mA
forward voltage	2 V
htsus	8541.40.2000
категория	Оптоэлектроника/Индикаторы и дисплеи
led colours	Red
luminous intensity	16 mcd
maximum operating temperature	+75°C
millicandela rating	16mcd
minimum operating temperature	-25°C
moisture sensitivity level (msl)	1 (Unlimited)
mounting type	Through Hole
number of characters	2
number of segments	7
operating temperature range	-25 →+75°C
package	Tray
package / case	18-DIP
партномер	8009707627
power dissipation	960mW
power dissipation (max)	60mW
reach status	REACH Unaffected
rohs status	ROHS3 Compliant
series	LB-602 A/K2
size / dimension	0.748"" H x 0.984"" W x 0.315"" D (19.00mm x 25.00
вес, г	10
voltage - forward (vf) (typ)	2V
Время загрузки	9:27:27
wavelength - peak	650nm
